How to Expose Services from an IPv6‑Only Ubuntu 24.04 VPS with Cloudflare Tunnel and Caddy (2025 Tutorial)

Introduction

Running services on an IPv6-only VPS offers significant advantages including reduced costs, improved performance, and future-proofing your infrastructure. However, exposing these services to the broader internet—where many users still rely on IPv4—presents a unique challenge.

This tutorial demonstrates how to securely expose web services from an IPv6-only Ubuntu 24.04 VPS using Cloudflare Tunnel for IPv4 accessibility and Caddy as a reverse proxy. You’ll learn to create a robust, production-ready setup that handles SSL termination, automatic certificate management, and seamless IPv4/IPv6 dual-stack connectivity.

Prerequisites

Before starting this tutorial, ensure you have:

  • An IPv6-only Ubuntu 24.04 VPS with at least 1GB RAM and 1 vCPU
  • Root or sudo access to your VPS
  • A domain name with DNS management access
  • A Cloudflare account (free tier sufficient)
  • Basic familiarity with command line operations
  • A web service to expose (we’ll use a simple HTTP server as an example)

Note: This tutorial assumes your VPS already has IPv6 connectivity configured. If you need help setting up an IPv6-only VPS, refer to our comprehensive guide on deploying IPv6-only Ubuntu VPS.

Step-by-Step Tutorial

Step 1: Update System and Install Dependencies

First, update your Ubuntu 24.04 system and install necessary packages:

sudo apt update && sudo apt upgrade -y
sudo apt install curl wget gnupg2 software-properties-common -y

Step 2: Install Caddy Web Server

Install Caddy using the official repository:

# Add Caddy repository
curl -1sLf 'https://dl.cloudsmith.io/public/caddy/stable/gpg.key' | sudo gpg --dearmor -o /usr/share/keyrings/caddy-stable-archive-keyring.gpg
curl -1sLf 'https://dl.cloudsmith.io/public/caddy/stable/debian.deb.txt' | sudo tee /etc/apt/sources.list.d/caddy-stable.list

# Install Caddy
sudo apt update
sudo apt install caddy -y

Verify the installation:

caddy version

Step 3: Set Up a Sample Web Service

Create a simple HTTP service that we’ll expose through our tunnel:

# Create a simple HTML file
sudo mkdir -p /var/www/html
echo '<!DOCTYPE html>
<html>
<head><title>IPv6 Service Demo</title></head>
<body>
<h1>Hello from IPv6-only VPS!</h1>
<p>This service is running on an IPv6-only server.</p>
</body>
</html>' | sudo tee /var/www/html/index.html

# Start a simple HTTP server on port 8080
sudo python3 -m http.server 8080 --directory /var/www/html &

Step 4: Configure Caddy Reverse Proxy

Create a Caddyfile configuration:

sudo nano /etc/caddy/Caddyfile

Add the following configuration (replace yourdomain.com with your actual domain):

yourdomain.com {
    reverse_proxy localhost:8080

    # Security headers
    header {
        # Enable HSTS
        Strict-Transport-Security max-age=31536000;
        # Prevent clickjacking
        X-Frame-Options DENY
        # Content type sniffing protection
        X-Content-Type-Options nosniff
    }

    # Logging
    log {
        output file /var/log/caddy/access.log {
            roll_size 100mb
            roll_keep 3
        }
    }
}

Create the log directory and start Caddy:

sudo mkdir -p /var/log/caddy
sudo systemctl enable caddy
sudo systemctl start caddy
sudo systemctl status caddy

Step 5: Install Cloudflare Tunnel (cloudflared)

Download and install the latest version of cloudflared:

# Download cloudflared for ARM64 or AMD64 (adjust URL based on your architecture)
wget https://github.com/cloudflare/cloudflared/releases/latest/download/cloudflared-linux-amd64.deb

# Install the package
sudo dpkg -i cloudflared-linux-amd64.deb

# Verify installation
cloudflared version

Step 6: Authenticate with Cloudflare

Authenticate cloudflared with your Cloudflare account:

cloudflared tunnel login

This command will open a browser window. Select the domain you want to use for the tunnel.

Step 7: Create and Configure the Tunnel

Create a new tunnel:

# Create tunnel (replace 'my-ipv6-tunnel' with your preferred name)
cloudflared tunnel create my-ipv6-tunnel

# Note the tunnel UUID from the output

Create a configuration file for the tunnel:

sudo nano ~/.cloudflared/config.yml

Add the following configuration (replace values with your tunnel UUID and domain):

tunnel: YOUR_TUNNEL_UUID
credentials-file: /root/.cloudflared/YOUR_TUNNEL_UUID.json

ingress:
  - hostname: yourdomain.com
    service: http://localhost:80
  - service: http_status:404

Step 8: Configure DNS and Route Traffic

Create a CNAME record pointing to your tunnel:

cloudflared tunnel route dns my-ipv6-tunnel yourdomain.com

Step 9: Run the Tunnel as a System Service

Install the tunnel as a system service:

sudo cloudflared service install
sudo systemctl enable cloudflared
sudo systemctl start cloudflared
sudo systemctl status cloudflared

Step 10: Test Your Setup

Test both IPv4 and IPv6 connectivity:

# Test from IPv4-only network
curl -4 https://yourdomain.com

# Test from IPv6 network
curl -6 https://yourdomain.com

# Check tunnel status
cloudflared tunnel info my-ipv6-tunnel

Best Practices

Security Considerations

  • Firewall Configuration: Since your services are exposed through Cloudflare Tunnel, configure your firewall to only allow essential connections. Consider deploying CrowdSec for enhanced protection.
  • SSL/TLS: Always use HTTPS. Caddy automatically manages Let’s Encrypt certificates, but ensure your tunnel configuration uses HTTPS endpoints.
  • Access Control: Implement Cloudflare Access policies for sensitive applications.
  • Regular Updates: Keep both Caddy and cloudflared updated to the latest versions.

Performance Optimization

  • Caching: Configure appropriate caching headers in your Caddy configuration for static content.
  • Compression: Enable gzip compression in Caddy for better performance over slower connections.
  • Monitoring: Set up monitoring for both your tunnel and web services to ensure high availability.
  • Resource Management: Monitor CPU and memory usage, especially if running multiple services. Consider our guide on VPS memory management.

Scaling Considerations

For production environments, consider:

  • Running multiple tunnel instances for redundancy
  • Using load balancing features in Cloudflare
  • Implementing health checks for your backend services
  • Setting up automated backups for your configuration files

Conclusion

You’ve successfully set up a robust solution for exposing services from an IPv6-only VPS using Cloudflare Tunnel and Caddy. This configuration provides several key benefits:

  • Universal accessibility through IPv4/IPv6 dual-stack support
  • Automatic SSL certificate management with Caddy
  • Enhanced security through Cloudflare’s edge network
  • Cost efficiency of IPv6-only infrastructure

This setup scales well for multiple services and provides a solid foundation for modern web applications. Whether you’re running microservices, APIs, or web applications, this tunnel configuration ensures reliable global connectivity.

Looking to deploy your own IPv6-only infrastructure? Explore our high-performance VPS solutions with native IPv6 support in Singapore, Sydney, and Amsterdam, featuring EPYC Milan processors and enterprise-grade NVMe storage.
