How to Deploy a Full Observability Stack on Ubuntu 24.04 VPS with OpenTelemetry Collector, Prometheus, Loki, Tempo, and Grafana (2025 Tutorial)

Modern applications require comprehensive observability to maintain optimal performance and reliability. This tutorial demonstrates how to deploy a complete observability stack using OpenTelemetry Collector, Prometheus, Loki, Tempo, and Grafana on Ubuntu 24.04 LTS. You’ll learn to collect metrics, logs, and traces from your applications in a unified monitoring platform.

Prerequisites

Before starting this observability deployment, ensure you have:

• Ubuntu 24.04 LTS VPS with minimum 4GB RAM and 2 vCPUs
• Root or sudo access to the server
• Docker and Docker Compose installed
• At least 20GB available storage space
• Basic understanding of containerized applications

If you haven’t installed Docker yet, run these commands:

sudo apt update
sudo apt install -y docker.io docker-compose-plugin
sudo systemctl enable --now docker
sudo usermod -aG docker $USER

Step-by-Step Tutorial

Step 1: Create Project Structure

Create a dedicated directory for your observability stack:

mkdir ~/observability-stack
cd ~/observability-stack
mkdir -p configs/{prometheus,loki,tempo,otel-collector,grafana}

Step 2: Configure Prometheus

Create the Prometheus configuration file:

cat > configs/prometheus/prometheus.yml << 'EOF'
global:
  scrape_interval: 15s
  evaluation_interval: 15s

scrape_configs:
  - job_name: 'prometheus'
    static_configs:
      - targets: ['localhost:9090']

  - job_name: 'otel-collector'
    static_configs:
      - targets: ['otel-collector:8888']

  - job_name: 'grafana'
    static_configs:
      - targets: ['grafana:3000']
EOF

Step 3: Configure Loki for Log Aggregation

Set up Loki configuration for centralized log management:

cat > configs/loki/loki.yml << 'EOF'
auth_enabled: false

server:
  http_listen_port: 3100
  grpc_listen_port: 9096

common:
  instance_addr: 127.0.0.1
  path_prefix: /tmp/loki
  storage:
    filesystem:
      chunks_directory: /tmp/loki/chunks
      rules_directory: /tmp/loki/rules
  replication_factor: 1
  ring:
    kvstore:
      store: inmemory

query_range:
  results_cache:
    cache:
      embedded_cache:
        enabled: true
        max_size_mb: 100

schema_config:
  configs:
    - from: 2020-10-24
      store: boltdb-shipper
      object_store: filesystem
      schema: v11
      index:
        prefix: index_
        period: 24h

ruler:
  alertmanager_url: http://localhost:9093
EOF

Step 4: Configure Tempo for Distributed Tracing

Create Tempo configuration for trace collection:

cat > configs/tempo/tempo.yml << 'EOF'
server:
  http_listen_port: 3200
  grpc_listen_port: 9095

distributor:
  receivers:
    otlp:
      protocols:
        grpc:
          endpoint: 0.0.0.0:4317
        http:
          endpoint: 0.0.0.0:4318

ingester:
  max_block_duration: 5m

compactor:
  compaction:
    block_retention: 1h

storage:
  trace:
    backend: local
    local:
      path: /tmp/tempo/traces
    wal:
      path: /tmp/tempo/wal
EOF

Step 5: Configure OpenTelemetry Collector

Set up the OpenTelemetry Collector as the central telemetry data processing hub:

cat > configs/otel-collector/otel-collector.yml << 'EOF'
receivers:
  otlp:
    protocols:
      grpc:
        endpoint: 0.0.0.0:4317
      http:
        endpoint: 0.0.0.0:4318

  prometheus:
    config:
      scrape_configs:
        - job_name: 'otel-collector'
          scrape_interval: 10s
          static_configs:
            - targets: ['0.0.0.0:8888']

processors:
  batch:

exporters:
  prometheus:
    endpoint: "0.0.0.0:8889"

  loki:
    endpoint: http://loki:3100/loki/api/v1/push

  otlp/tempo:
    endpoint: http://tempo:4317
    tls:
      insecure: true

service:
  pipelines:
    traces:
      receivers: [otlp]
      processors: [batch]
      exporters: [otlp/tempo]

    metrics:
      receivers: [otlp, prometheus]
      processors: [batch]
      exporters: [prometheus]

    logs:
      receivers: [otlp]
      processors: [batch]
      exporters: [loki]
EOF

Step 6: Create Docker Compose Configuration

Deploy the complete observability stack with Docker Compose:

cat > docker-compose.yml << 'EOF'
version: '3.8'

services:
  # OpenTelemetry Collector
  otel-collector:
    image: otel/opentelemetry-collector-contrib:0.91.0
    container_name: otel-collector
    command: ["--config=/etc/otelcol-contrib/otel-collector.yml"]
    volumes:
      - ./configs/otel-collector/otel-collector.yml:/etc/otelcol-contrib/otel-collector.yml
    ports:
      - "4317:4317"   # OTLP gRPC receiver
      - "4318:4318"   # OTLP HTTP receiver
      - "8888:8888"   # Prometheus metrics
      - "8889:8889"   # Prometheus exporter
    depends_on:
      - tempo
      - loki

  # Prometheus for metrics
  prometheus:
    image: prom/prometheus:v2.48.0
    container_name: prometheus
    ports:
      - "9090:9090"
    volumes:
      - ./configs/prometheus/prometheus.yml:/etc/prometheus/prometheus.yml
      - prometheus_data:/prometheus
    command:
      - '--config.file=/etc/prometheus/prometheus.yml'
      - '--storage.tsdb.path=/prometheus'
      - '--web.console.libraries=/etc/prometheus/console_libraries'
      - '--web.console.templates=/etc/prometheus/consoles'

  # Loki for logs
  loki:
    image: grafana/loki:2.9.2
    container_name: loki
    ports:
      - "3100:3100"
    volumes:
      - ./configs/loki/loki.yml:/etc/loki/local-config.yaml
      - loki_data:/tmp/loki
    command: -config.file=/etc/loki/local-config.yaml

  # Tempo for traces
  tempo:
    image: grafana/tempo:2.3.0
    container_name: tempo
    ports:
      - "3200:3200"
      - "4317:4317"
    volumes:
      - ./configs/tempo/tempo.yml:/etc/tempo/tempo.yml
      - tempo_data:/tmp/tempo
    command: ["-config.file=/etc/tempo/tempo.yml"]

  # Grafana for visualization
  grafana:
    image: grafana/grafana:10.2.0
    container_name: grafana
    ports:
      - "3000:3000"
    environment:
      - GF_SECURITY_ADMIN_PASSWORD=admin123
    volumes:
      - grafana_data:/var/lib/grafana
    depends_on:
      - prometheus
      - loki
      - tempo

volumes:
  prometheus_data:
  loki_data:
  tempo_data:
  grafana_data:
EOF

Step 7: Deploy the Observability Stack

Launch all services with a single command:

docker compose up -d

Verify all containers are running:

docker compose ps

Step 8: Configure Grafana Data Sources

Access Grafana at http://your-vps-ip:3000 (admin/admin123) and add these data sources:

• Prometheus: http://prometheus:9090
• Loki: http://loki:3100
• Tempo: http://tempo:3200

Best Practices

Performance Optimization:

• Configure retention policies to manage storage usage effectively
• Use appropriate scrape intervals based on your monitoring requirements
• Implement log filtering to reduce noise in your observability pipeline

Security Considerations:

• Change default Grafana credentials immediately
• Implement network segmentation using Docker networks
• Consider enabling authentication for production deployments
• Use CrowdSec protection for external-facing services

Monitoring Best Practices:

• Set up alerting rules in Prometheus for critical metrics
• Create comprehensive dashboards covering infrastructure and application metrics
• Implement distributed tracing in your applications using OpenTelemetry SDKs

Conclusion

You’ve successfully deployed a production-ready observability stack featuring metrics collection with Prometheus, log aggregation through Loki, distributed tracing via Tempo, and unified visualization in Grafana. This comprehensive monitoring solution provides the foundation for maintaining application performance, troubleshooting issues, and ensuring system reliability.

The OpenTelemetry Collector serves as your telemetry data processing hub, enabling seamless integration with your existing applications. For high-performance deployment of observability stacks, consider our Singapore VPS solutions with dedicated resources and enterprise-grade storage.

To further enhance your infrastructure, explore our guides on deploying production-ready Kubernetes clusters and implementing automated backup strategies for your monitoring data.
